ELISA Rotary Tube Mixer

20% OFF list price as part of our FALL Sale! On now until October 18th, 2024! Product Introduction The rotary tube mixer is suitable for conventional mixing scenarios in industries such as biology, medicine, and chemical engineering. However, it is not recommended for use in a cold storage. Product Features Rotary operation for gentle and thoroµgh mixing Adjustable angle range: 0-90 for single-layer adapter, 50°-90° double-layer adapter Adjustable speed range: 0-80rpm Accurate speed Low noise MµLtiple specifications of clips can be freely combined, suitable for 1.5mL, 2.0mL, 5mL, 10mL, 15mL, and 50mL centrifµge tubes Memory function: the parameters at startup are the same as the last settings before the last shutdown Products Parameters Product Name Rotary Mixer Environmental temperature 5°C~40°C Relative humidity ≤80% Relative humidity AC100V~AC240V AC power 50 Hz/60 Hz Output power 24 V，1.5 A， 36 W Motor type Stepper motor Speed range 10-80 rpm Time range 1m-99h59m Angle range 0-90° for single-layer adapter, 50°C-90° double-layer adapter Speed display Digital display Operating mode Continuous mode Voltage 100-240 V，50/60 Hz Input power 36 W Dimensions 176×260×306 mm Product weight 2.45 Kg Machine Description 1.Structural Diagram 2.Optional Accessories Model Description SMV-R-A 6×1.5(2.0)mL+6×5mL+6×15(10)mL+6×50mL SMV-R-B 12×1.5(2.0)mL+6×15(10)mL+6×50mL SMV-R-C 30×1.5(2.0)mL SMV-R-D 25×5mL SMV-R-E 20×15(10)mL SMV-R-F 10×50mL SMV-R-G 7×15(10)mL+7×50mL SMV-R-H Double-layer tray connecting rod If you need to customize other models or modµLes, please get in touch with the supplier 3.Installation Instructions 1.Ensure a good working environment, free from explosive and flammable materials. 2.Open the package and check whether the instrument accessories are complete, then place the instrument on a horizontal workbench. 3.If mµLtiple instruments are used simµLtaneously, please maintain a distance of more than 25cm between each equipment. 4.Before connecting the instrument to the power supply, please ensure that the input voltage meets the product standard. 5.Before installing the accessories, first turn off the power, gently remove the original accessories, and then connect the replacement accessories with screws. Before each use of the instrument, please confirm that the instrument and its accessories are not damaged. Operation Guide I. Place the instrument on a stable, level workbench. Connect the power supply and turn on the power switch 2. Touch the "Function switch" button to select the parameter you want to set, The selected parameter will blink, Use the "increase" or "Decrease" buttons to set it to the desired value. 3.0nce the value is set, touch the "Start/Stop" button to start the instrument. 4.The instrument allows adjusting the speed during operation. ifyou need to adjust the time, you must pause the instrument first and then use the function switch button to set. 5. Loosen the l-shaped handle screw to adjust the angle of the instrument. After adjusting the angle, be sure to tighten the L-shaped handle screw to secure the angle. lf you notice any angle changes during use, check if the l-shaped handle screws are tightened. it is important to tighten both sides of the L-shaped handle screws simµLtaneously for better angle stability. 6.Replace the adapter, remove the hand-twist screw, align the desired adapter with the mounting hole, and then tighten the hand. twist screw. 7.When installing the double-layer adapter, use the double-layer tray connecting rod. Press the threaded end 8.The rotator mixer has a locked-rotor function. in case of a locked-rotor caused by improper operation, the instrument will self-correct and continue running. The correction process takes about 10s. 9.If the instrument makes a "Dada Dada" noise during operation, it is determined to be caused by loose manual screw nuts. please tighten the manual screw nuts.
